906-362A1012D10200 AF13.65侧插短体外弯内直无边铜壳PBT白胶

发布时间： 2021-05-21 品牌：精拓金资料类型：产品图纸语言：中文

代理服务

技术支持

采购服务

●注：

■材料：
▲外壳：热塑性塑料，UL94V~0（ROHS，HF）▲触点：磷青铜C5191-EH/C2680-EH，T=0.25mm▲外壳：铜合金T=0.30mm
■饰面：
▲联系人：

◆接触面镀金15u，
◆焊料区域至少镀锡80u
◆最小50u。全部镀镍。
▲外壳：最小50u。全部镀镍。

■说明：
▲评级：

◆额定电压500V AC/DC。

◆额定电流：最大2 A。
▲电气：

◆绝缘电阻（ElA-364-21）：
1000mΩ IMinute的最低电压为500V/DC。

◆接触电阻（EIA-364-23）：
30mΩ 20mV时最大值，50mA
◆介质耐受电压（EIA-364-20）：
500V/AC电压下无放电、闪络或击穿
■拔塞力应在1.0kgf和2.00kgf之间
■接触面：
▲选择性闪光▲精选黄金3U“▲精选金5U“▲精选黄金库存15件▲精选金30U“
