鱼眼端子(Press-Fit)介绍

发布时间： 2023-11-24 品牌：长江连接器资料类型：商品及供应商介绍语言：中文

代理服务

技术支持

采购服务

●何为鱼眼端子
■在各大标准或者行业标准中，由英文名Press-Fit翻译过来即为压配式端子，国内很多公司因其形状中有很小的酷似鱼眼的结构，故而大家称呼其为鱼眼端子
●鱼眼端子优点：
■制造简单，仅一套有冲压模具即可完成（板材冲压--电镀--裁切压配）；
■无焊接过程，降低的成本，提高了产品质量，且环保；
■相比较于锡焊，寿命好，强度高（有可靠的电接触位面）；
■具备一定的通用互换性。
