产品目录
| 订货型号 | 型号系列 | 品类 | 描述 | 封装/外壳/尺寸 | 生命周期 | 停产时间 | H | W | N.W. | DIP |
|
2243-1XXRXXCUNT1;2243
|
排母连接器;板对板连接器
|
排母连接器;板对板连接器;H=4.3,W=2.75,DIP=2.7,G/F,1350/Reel,NW:0.426g
|
-
|
有效(ACTIVE)
|
-
|
4.3
|
2.75
|
0.426g
|
2.7
|
|
|
2243-1XXRXXCUNT1;2243
|
排母连接器;板对板连接器
|
排母连接器;板对板连接器;H=4.3,W=2.75,DIP=2.7,Gold Flash,9PCS/Tube,NW:1.243g
|
-
|
有效(ACTIVE)
|
-
|
4.3
|
2.75
|
1.243g
|
2.7
|
|
|
2243-1XXRXXCUNT1;2243
|
排母连接器;板对板连接器
|
排母连接器;板对板连接器;H=4.3,W=2.75,DIP=2.7,G/F,12/Tube,NW:0.862G
|
-
|
有效(ACTIVE)
|
-
|
4.3
|
2.75
|
0.862G
|
2.7
|
|
|
2243-1XXRXXCUNT1;2243
|
排母连接器;板对板连接器
|
排母连接器;板对板连接器;H=4.3,W=2.75,DIP=2.7,Gold Flash,45PCS/Tube,NW:0.241g
|
-
|
有效(ACTIVE)
|
-
|
4.3
|
2.75
|
0.241g
|
2.7
|
|
|
2243-1XXRXXCUNT1;2243
|
排母连接器;板对板连接器
|
排母连接器;板对板连接器;H=4.3,W=2.75,DIP=2.7,G/F,20/Tube,NW:0.532G
|
-
|
有效(ACTIVE)
|
-
|
4.3
|
2.75
|
0.532G
|
2.7
|
|
