大家好,通信项目上面的信号口防雷有推荐方案吗？
-
创建于2020-10-24
1个回答
-
![]()
![]()
- 用户27254126 Lv7 (0)
- 有的，推荐使用硕凯的sc1812-90csmd，他的通流量可达3KA，后级用个se03d3d01gw，容值低于1.2PF，不会影响信号传输，整套方案可以过10/700us＆5/320us:±6KV，https://www.sekorm.com/product/84288.html
- 创建于2020-10-24
- |
- +1 赞 0
- 收藏
