Fast Recovery Full-Wave Bridge Rectifiers RMB2S Thru RMB6S with Fast Reverse Recovery Time of 150ns Maximum

知识图谱

时间： 2023-08-20 来源：SMC News 发布者：桑德斯微电子器件（南京）有限公司

代理服务

技术支持

采购服务

The RMB2S thru RMB6S series of devices is a family of Fast Recovery Full-Wave Bridge Rectifiers packaged in the space-saving MB-S case. The RMB series has a forward current rating of 0.8A, a high single cycle surge (8.3ms) rating of 30A, and high reverse voltage capability of 200V to 600V. The entire family (200V thru 600V) of bridges has a fast reverse recovery time of 150ns maximum which is needed for full-wave rectification of higher frequency signals. The series utilizes glass passivated silicon die which minimizes reverse leakage currents and enhances device reliability. The combination of a very small package footprint, high reverse voltage capability, and fast recovery time make this series of devices ideal for both offline rectification and higher frequency full-wave rectification in space-constrained applications.

Features

Continuous forward current capability of 0.8A (T_A=30℃, alumina substrate)
High reverse voltage capability up to 600V
Fast reverse recovery time of 150nS maximum
Low forward voltage drop of 0.9V Typ. at 0.4A, T_A=25℃
Very small package footprint (4.7mm x 7.0mm)
High forward surge rating of 30A necessary for reactively loaded circuits
Glass passivated silicon die for high reliability

Applications

Off-line input rectification for industrial, consumer, telecom, and white goods
High frequency full-wave rectification applications
Steering diodes
Charging circuits
Switching and linear power supplies

Maximum Ratings @TA=25℃ unless otherwise specified

Electrical Characteristics:
